File:Swedish Navy T21 class MTB-drag.png

Size of this preview: 800 × 502 pixels. Other resolution: 1,024 × 642 pixels.

Original file (1,024 × 642 pixels, file size: 85 KB, MIME type: image/png)

Summary

Description	(en) Total (green) and parts, displacement (red), planing (cyan) and rudder assembly (purple), of the hydrodynamic drag of the Swedish Navy T21 class MTB from a single acceleration run in JSBSim/standalone. The blue line is a real tow tank result traced from a diagram from "Resultat av släpförsök med svenska patent nr. 109626", A. F. Nordström, Statens Skeppsprovningsanstalt, Göteborg, 1941-10-01 available as an image (ID 2008:25:869:1) from Sjöhistoriska museet under CC BY-SA. It is not clear whether this model test result actually was for the T21-class 20 meter MTB (not yet in service in 1941) or the earlier, but very similar, T15-class 18.7 meter MTB.
Date	3 December 2016 (2016-12-03)
Source	Own work
Author	Anders Gidenstam
